Ceramic balls are made from high-quality chemical porcelain raw materials. It has the characteristics of high strength, high chemical stability and thermal stability.It is widely used in petroleum, chemical, fertilizer, natural gas and environmental protection industries.
Keywords:
Category:
Industrial Ceramic
E-mail:
154872569@qq.com
Ceramic Ball Details
Product Description
Ceramic balls are made from high-quality chemical porcelain raw materials. It has the characteristics of high strength, high chemical stability and thermal stability. Ceramic ball can withstand high temperature, high pressure and corrosion of acids, alkalis, salts and various organic solvents. It is widely used in petroleum, chemical, fertilizer, natural gas and environmental protection industries. It is used as the support material and tower packing of the catalyst in the reactor. It can buffer the impact of the liquid and gas entering the reactor on the catalyst, protect the catalyst, and improve the liquid in the reactor. And gas distribution. Its main function is to increase the gas or liquid distribution point, support and protect the active catalyst with low strength.
65-92% Alumina Grinding ceramic ball are suitable fo applications for ball mill, sand mill, pot mill librating mill and other fine breaking plants.
Features
(1) The main component is high-quality alumina with high whiteness, which has no effect on the quality of the material being ground.
(2) Rolling and isostatic pressing are used, with a large specific gravity, which can greatly improve the grinding efficiency, reduce the grinding time, and effectively increase the effective volume of the ball mill, thereby increasing the amount of grinding material added.
(3) Low abrasion, can greatly extend the service life of the grinding body.
(4) Can withstand more than one thousand degrees of high temperature, acid, alkali and corrosion resistance
Application
It has high strength, high hardness, high wear resistance, specific gravity, small size, high temperature resistance, corrosion resistance, pollution-free and other excellent characteristics and is widely used in thick and hard materials of different types of ceramics, enamel, glass, chemical plants Finishing and deep processing are the grinding media for fine grinding equipment such as ball mills, pot mills, vibratory mills, etc. Its grinding efficiency and wear resistance are much better than ordinary ball stones or natural pebbles.
Physical And Chemical Indicators
Brand |
AGB-75 |
AGB-92 |
AGB-92S |
AGB-95 |
Al2O3(%) |
≥75 |
≥92 |
≥92 |
≥95 |
Bulk density(g/cm3) |
≥3.20 |
≥3.65 |
≥3.68 |
≥3.68 |
Wear Loss(%) |
≤0.015 |
≤0.01 |
≤0.008 |
≤0.01 |
Hardness(Mohs) |
|
9 |
9 |
9 |
Water Absorption(%) |
≤0.02 |
≤0.01 |
≤0.01 |
≤0.01 |
Color |
greyish white |
white |
white |
white |
Size
|
Rolling: Ø0.5-50mm Pressing: Ø13-90mm Size can be customized |
|||
Application |
Ball Mill and Regenerator |
Pictures
