Stainless Steel Anchors are structural parts that connect and fix lightweight refractory materials such as ceramic fibers, lightweight insulating bricks, and unshaped refractory materials with the metal siding of the kiln; according to the industrial kiln structure, furnace temperature, and ambient atmosphere, different types of anchors should be selected. Structures and anchors of different materials; anchors used for refractory materials within the classification temperature range of 1050℃-1400℃. According to the environment and status of the anchor used on different devices, stainless st
Keywords:
Category:
Insulation Thermal Material
E-mail:
154872569@qq.com
Stainless Steel Anchor Details
Stainless Steel Anchors are structural parts that connect and fix lightweight refractory materials such as ceramic fibers, lightweight insulating bricks, and unshaped refractory materials with the metal siding of the kiln; according to the industrial kiln structure, furnace temperature, and ambient atmosphere, different types of anchors should be selected. Structures and anchors of different materials; anchors used for refractory materials within the classification temperature range of 1050℃-1400℃.
According to the environment and status of the anchor used on different devices, stainless steel anchor can be pided into module-specific angle iron anchor, diamond anchor, butterfly anchor, empty hanging anchor, corner anchor; folding Herringbone anchors for blocks: fast cards, rotating cards, threading ribs, screw nuts, threading ribs. U-shaped nails, V-shaped nails and so on.
Features
Wide temperature range,from800C to 1400C
Various forms of anchors: straight, cross, L, etc.
Reasonable structure
Firm, and reliable anchor
Install easily and quickly
Applications
Fix ceramic fiber modules and folded modules
Fix all kinds of refractory brick,cement and castable
Anchor fiber flame plating
Fix and joint high temperature board and installation
Physical And Chemical Indicators
Product Type |
Anchor Products |
|
Classification Temperature(°C ) |
1260 |
1400 |
Name |
Pin,Washer,Insultwist Stud,Anchor Bolt |
|
Material |
SS304 |
SS310 |
Application Temperature (°C) |
870 |
1035 |
Technical Criteria |
OCr18Ni9 |
Cr25Ni20 |
Packing |
Wooden Box |
Pictures
Semi-silica brick refers to an aluminum-silicon refractory product with a SiO2 content of greater than 65% and an Al2O3 content of 15% to 30%. They generally use clay containing quartz impurities or native kaolin refractory clay or tailings and pyroph...
The Al2O3 content of anchor bricks is above 55%, and some users require that the alumina content reach 75%, and the load softening temperature of 75% bricks reaches 1550C. However, in actual use, anchor bricks with high aluminum content cannot be enough. The key is Flexibility is the most important t...
Products Desc
Products Description The main components of alkali resistant bricks are clay, high alumina, quartz sand, bauxite and other alkali resistant materials, among which quartz sand and bauxite can improve alkali resistance, clay and high alumina can increase sintering pressure, so that alkali-resistant bri...
